Multipurpose meeting room protection unit
«Ultrasonic 120 Phantom»

Ultrasonic 120 Phantom
$ 1750
€ 1560
Уменьшить Увеличить


Задать вопрос Задать вопрос Видеоинструкция/обзоры Видеоинструкция/обзоры
Скачать инструкцию Скачать инструкцию

Weight (in package), kg: 3,5     Packing size, mm: 600x600x100


  • Voice recorder jamming type:
    • Ultrasonic – 120 emitters; Acoustic suppression.
  • 10 frequency types:
    • GSM 900, GSM 1800, 3G 2100, GPS 1500, Wi-Fi 2400, Bluetooth 2400-2468 MHz, Video recorders 1200, LTE 4G Mobile 850, LTE 4G 2500, LTE 4G 2620-2690.

Дорогие друзья! При покупке на сумму от 15 т.р. Вы можете выбрать подарок!

«Ultrasonic 120 Phantom»   - aimed to secure your meeting room or any large indoor space from recording or transmitting information by jamming voice recording devices, mobile communication and internet.

Ultrasound affects sensitive microphone membrane of all modern smartphones (Apple, Samsung etc.) and EDIC-mini Tiny microphones, which makes voice recording impossible.

Low frequency “Voice Chorus” acoustic suppression. On the record would sound like a multiple voice choir making it incomprehensible.

The unit is equipped with 10 frequency suppressor, able to jam data transmission via phone calls, sms messages, and most common communication standards - 3G/4GLTE/4Gmobile.

Combined protection mode. Using both types of protection – jamming recording and data transmission, provides your negotiations or talks with maximum security.

This unit is able to protect from laser microphones that can read or pick up the information through the window. We mangled to solve this issue with vibroacoustic emitters which are able to block information leakage through the window.

«Ultrasonic 120 Phantom» review

Attention ! Jamming is performed with noiseless (ultrasonic) mode!
This means that your partners won't hear any suspicious sound of the operating unit!

Special Features:

  • Designed after Armstrong type 600x600 (millimeter) ceiling panel, with 120 built-in ultrasonic emitters 90dB each. Can be installed into the ceiling, right above the place or table, where you hold negotiations. Due to its position and celling panel look it won’t drag much of attention.

  • Protection against laser microphones. Vibroacoustic protection mounted on the window will protect your information from reading through the windows by laser microphones and laser stethoscopes.

  • Space between panels and main ceiling is also protected from hidden microphones and recording devices by acoustic interference.

  • Superpowerfull ultrasonic radiation. 120 ultrasonic emitters with different frequency and power ( up to 90dB) , influence on voice recording device’s sensitive microphone membrane. Due to this feature you will have large space fully protected from recording.

  • We produce every unit according to the features/size etc. of the room, provided by our customers. This way we achieve full security of the particular room.

  • Low frequency acoustic radiation creates noise background, making any recorded sound incomprehensible. As well as other protection modes - can be adjusted by using remote control panel.

  • 10 frequencies of wireless/mobile internet and mobile communication jamming. This device blocks any data transmission via GSM 900, GSM 1800, 3G 2100, GPS 1500, Wi-Fi 2400, Bluetooth 2400-2468 MHz, Video recorders 1200, LTE 4G Mobile 850, LTE 4G 2500, LTE 4G 2620-2690.

  • Remote control panel. Allows to choose one of three modes of protection on activate all 3 at the same time, as well as to adjust acoustic mode volume.

  • Acoustic suppression adjustable volume. To create comfortable environment for negotiations process.


Комплексное устройство для защиты информации «UltraSonic-120-Рhantom» общий вид
Комплексное устройство для защиты информации «UltraSonic-120-Рhantom» подключение
Комплексное устройство для защиты информации «UltraSonic-120-Рhantom» панель управления
Комплексное устройство для защиты информации «UltraSonic-120-Рhantom» запотолочный динамик



Usage

Voice recorder and mobile communication jammer «Ultrasonic 120 Phantom» meant to be installed into ceiling of a meeting/conference room, replacing one of standard 60x60cm ceiling panel. To provide maximum security the jammer should be installed right above the negotiations table.

How it works

Voice recorder and mobile communication jammer works as a directional ultrasonic radiator, which interferes with sensitive membrane of voice recording devices. Acoustic suppression works as an additional protection mode. Despite voice recording protection, the jammer blocks wireless communication data transmission.

Technical features.

  • Ultrasound signal power up to 2,5 meter distance – 90dB
  • Ultrasound emitters – 120x
  • Ultrasound frequency range angle -100-120 degree
  • Low-frequency acoustic emitters – 2x
  • Jamming modes -3x
  • Jamming frequencies:
    • GSM 900;
    • GSM 1800;
    • 3G 2100;
    • GPS 1500;
    • Wi-Fi 2400;
    • Bluetooth 2400-2468 MHz;
    • Video recorders 1200;
    • LTE 4G Mobile 850;
    • LTE 4G 2500;
    • LTE 4G 2620-2690;
  • Quantity of jamming frequencies -10
  • Suppression range –up to 15 m
  • Ceiling panel size -600x600 (millimeters)

CONFIDENT SUPPRESSION RANGE OF ULTRASONIC SUPPRESSOR
WITH A VARIETY OF DEVICES (VALUES GIVEN IN METRES)

  Mobile phones (smartphones) Digital voice recorders
  iPhone Samsung Galaxy LG G2 Mini Asus Zen-
fone 5
Xiao-
mi Red-
mi 4
Edic - Mini LCD B8 - 17920 Olym-
pus VP - 10
Sony ICD - TX 650 N
  5S 6S 7 Note 4 J7 S Duos
UltraSonic-120 Phantom 10 5 4 5 6 5 4 2 6 9 4 4
UltraSonic-SHAJBA-50-GSM 10 5 4 5 6 5 4 2 6 9 4 4
UltraSonic-TUBA-50-GSM 10 5 4 5 6 5 4 2 6 9 4 4
UltraSonic-50-GSM 10 4 2.5 4 6 4 4 2 5 9 2.5 2.5
UltraSonic-Ring-24-GSM 10 3 2.5 4 5 4 4 2 4.5 9 2.5 2.5
UltraSonic-24-GSM 10 3 2.5 4 5 4 4 2 4.5 9 2.5 2.5
UltraSonic-24-Light 10 3 2.5 4 5 4 4 2 4.5 9 2.5 2.5
UltraSonic-Folder-24-GSM 10 3 2.5 4 5 4 4 2 4.5 9 2.5 2.5
UltraSonic-18-GSM 10 3 2 3 4 3 2.5 1.5 4.5 8 2.5 2.5
UltraSonic-18-Light 10 3 2 3 4 3 2.5 1.5 4.5 8 2.5 2.5
UltraSonic-6-SPY 5 1.5 1 1 1 1 1 0.5 1.5 5 1 1
UltraSonic HDD-6.0 5 1.5 1 1 1 1 1 0.5 1.5 5 1 1
UltraSonic Power Bank-6.0 5 1.5 1 1 1 1 1 0.5 1.5 5 1 1
Chameleon Speaker-12 Light 7 2 1.5 2 3 2 1.7 1 3 5.5 1.7 1.7
Chameleon Speaker-12 Dual 7.5 2.5 2 2.5 3.5 2.5 2.5 1.5 3.5 6 2 2
Chameleon Speaker-12 GSM 7 2 1.5 2 3 2 1.7 1 3 5.5 1.7 1.7
Chameleon 12-GSM-Handbag 7 2 1.5 2 3 2 1.7 1 3 5.5 1.7 1.7
Chameleon Clutch-12-Light 7 2 1.5 2 3 2 1.7 1 3 5.5 1.7 1.7
